STUMP GRINDER Skid Steer and 3-Point Mount

THE ALLIED BY FARM KING STUMP GRINDER CAN CUT THROUGH EVEN THE HARDEST STUMPS.

The impressive 45 degree swing arc allows the stump grinder to cover greater surface areas of larger trees. The grinder is easily controlled using the tractor or skid steer hydraulic levers. Both 3-point hitch grinder models use a slip clutch with the skid steer unit using system pressure.

Model 2628 3633 2628H
Hitch Cat.I Cat.I/II Universal Skid Steer
Cut Height (above ground/below ground0 18/10 18/15 18/10
Number of Teeth 33 42 33
Weight 660 lb 880 lb 757 lb

Features

  • Cutting wheel design provides a smoother cutting action and higher productivity
  • Durable carbide-tipped cutting teeth are economical and easy to replace
  • Stabilizer bar provides solid footing during operation
  • Maneuverable - goes anywhere a tractor or skid steer can; gets into tight places
  • Easy to operate - hydraulic controls allow easy operation from the seat of the power unit using existing hydraulic controls
  • Hardened bushings and grease zerks used at major pivot points for increased reliability and extended service life
  • Standard pressure relief valve for precise control of cutting feed rate
  • Rubber deflector helps control chips and debris during grinding
  • Parking stand for easy storage
  • Hydraulic model has quick attach universal skid steer hitch system

Manuals

Stump Grinder Date Posted
Operator and Parts Manual - 2010 July 2010
