TEDDERS Models RT10, RT17, RT19, RT24

FARM KING OFFERS MOUNTED AND PULL TYPE TEDDERS FOR SPREADING, AERATING AND TURNING OF FORAGE.

Farm King Tedders evenly spread and mix forage so that it is uniformly dried and prepared for baling or processing. Model RT10 is ideal for smaller field structures and features a robust design for low maintenance and long life.

Model RT10 RT17 RT19 RT24
Working Width 10' (310 cm) 17' (520 cm) 19' (570 cm) 24 (745 cm)
Transport Width 8' 2" (250 cm) 9' 2" (280 cm) 10' 5" (320 cm) 9' 8" (300 cm)
Working Speed 9 mph (14 kph) 9 mph (14 kph) 9 mph (14 kph) 9 mph (14 kph)
Rotors/Arms Per Rotor 2 / 6 4 / 6 4 / 6 6 / 6
Weight 490 lb (222 kg) 1,275 lb (578 kg) 1,400 lb (635 kg) 1,918 lb (870 kg)
RT10
Farm King offers mounted and pull type tedders for spreading, aerating and turning of forage. Farm King Tedders evenly spread and mix forage so that it is uniformly dried and prepared for baling or processing. Model RT10 is ideal for smaller field structures and features a robust design for low maintenance and long life.
RT17 / RT19 / RT24
High capacity mounted and pull type tedders for even spreading, aerating and turning of forage. Farm King Tedder models RT17, RT19 and RT24 feature hydraulic fold and tilt (tilt optional on model RT17) to quickly change from transport to working position from the cab.

Features

UNIQUE TINE DESIGN
The unique tines on all Farm King Tedders ensure that all of your hay is picked up and distributed evenly. The tines also allow the tedder to work at a steep operating angle, without leaving hay between the rotors.
HIGHER QUALITY
Tedding provides you with higher quality forage and allows you to get your crop off the field faster. Farm King Tedders reduce operating costs, by working at relatively low revolutions and high driving speeds. Operating at 8-10 mph gives you optimum fuel economy while tedding.
MAKING PROFITABLE HAY
Tedding provides you with higher quality hay and allows you to get your crop off the field faster. Farm King Tedders evenly spread and mix forage so that it is uniformly dried and prepared for baling or processing. Flexible steel tines lightly aerate the forage without causing damage. Models RT17 and RT19 are ideal for medium farms while model RT24 is best suited for high capacity operations.
Featuring large 16" and 18" tires (40 and 46 cm), model RT24 is able to follow the path of the tractor even under difficult conditions. Farm King Tedders reduce operating costs, by working at relatively low revolutions and high driving speeds. Operating at 8-10 mph gives you optimum fuel economy while tedding.

Manuals

Tedder - 10 Date Posted
Operator and Parts 2016 August 2016
Vortex Tedder - 17 & 19 Date Posted
Operator and Parts 2016 June 2016
Vortex Tedder - 24 Date Posted
Operator and Parts 2016 June 2016
Tedder Date Posted
Operator and Parts 2012 January 2012
