ROTARY TILLER Series 25, 45, 65

FARM KING HAS A COLLECTION OF ROTARY TILLER MODELS TO SUIT YOUR GARDEN AND LANDSCAPING NEEDS.

The tiller attaches to the three-point hitch and is designed to fit a variety of tractors, from 12 hp to 65 hp. Tilling widths range from 36" to 54" in the 25 Series and from 55" to 69" in the 45 Series. The 65 Series is available in 68" and 77" widths.

SERIES 25
Model TL236 36" (0.9 m) tillage width, 3-point hitch Category I For tractors 20 - 45 hp
Model TL245 45" (1.1 m) tillage width, 3-point hitch Category I For tractors 25 - 55 hp
Model TL254 54" (1.4 m) tillage width, 3-point hitch Category I For tractors 25 - 55 hp
SERIES 45
Model 4560 55" (1.4 m) tillage width, 3-point hitch Category I For tractors 26 - 65 hp
Model 4572 69" (1.8 m) tillage width, 3-point hitch Category I For tractors 35 - 65 hp
SERIES 65
Model 6572 68" (1.7 m) tillage width, 3-point hitch Category I For tractors 25 - 65 hp
Model 6582 77" (2.0 m) tillage width, 3-point hitch Category I For tractors 35 - 65 hp
AVAILABLE IN THESE COLOURS:

Features

SIDESHIFT
Getting close to fences, hedges or covering a tire track is easy with the sideshift feature. The entire unit can be pushed to one side while the PTO shaft remains in line with the tractor. The 45 & 72" 65 Series tiller is capable of side shift allowing models to be moved 6" either left or right. The 6582 has a standard offset of 10" (non-adjustable).
FEATURES
  • The rotator tilling shaft is equipped with four to eight flanges, depending on the model.
  • Flanges on all series are available with four tines, and six tines per flange are standard on the 65 Series.
  • Housed in a sealed oil bath, the chain tightener assembly is resistant to heat, dust, debris and moisture, which reduces maintenance and enhances the longevity of the chain and sprockets.
  • Farm King Rotary Tillers come standard with a parking jack and height adjustable skid shoes.

Manuals

45 Series Date Posted
Operator and Parts 2011 August 2011
Operator and Parts 2010 November 2010
Operator and Parts 2009 December 2008
Operator and Parts 2008 October 2007
Operator and Parts 2007 July 2006
Operator and Parts 2006 July 2005
Operator and Parts 2005 November 2004
Operator and Parts 2004 November 2003
65 Series Date Posted
Operator and Parts 2011 August 2011
Operator and Parts 2010 November 2010
Operator and Parts 2009 December 2008
Operator and Parts 2008 October 2007
Operator and Parts 2007 July 2006
Operator and Parts 2006 June 2005
Operator and Parts 2005 November 2004
Operator and Parts 2004 November 2003
